CSHDD16-100C TR13
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CSHDD16-100C TR13 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CSHDD16-100C TR13 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CSHDD16-100C TR13 |
|---|---|
| Manufacturer | Central Semiconductor |
| Description | DIODE ARRAY SCHOTTKY 100V D2PAK |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $1.109 | $1.00 | $0.804 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | CSHDD16-100C TR13 | Manufacturer | Central Semiconductor |
|---|---|---|---|
| Description | DIODE ARRAY SCHOTTKY 100V D2PAK | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 38127 pcs | Data sheet | CSHDD16-40C,60C,100C,200C |
| Category | Discrete Semiconductor Products | Voltage - Forward (Vf) (Max) @ If | 1.1V @ 16A |
| Voltage - DC Reverse (Vr) (Max) | 100V | Supplier Device Package | D2PAK |
| Speed | Fast Recovery = 200mA (Io) | Series | - |
| Packaging | Cut Tape (CT) | Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB |
| Other Names | CSHDD16-100C CT CSHDD16-100C CT-ND CSHDD16-100CCT |
Operating Temperature - Junction | -65°C ~ 175°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 15 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Diode Type | Schottky | Diode Configuration | 1 Pair Common Cathode |
| Detailed Description | Diode Array 1 Pair Common Cathode Schottky 100V 16A Surface Mount TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | Current - Reverse Leakage @ Vr | 50µA @ 100V |
| Current - Average Rectified (Io) (per Diode) | 16A |
