Home > Products > Switches > Rocker Switches > V2D1S00B-00000-000

V2D1S00B-00000-000

V2D1S00B-00000-000

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy V2D1S00B-00000-000 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	V2D1S00B-00000-000
Manufacturer	Carling Technologies
Description	SWITCH ROCKER SPST-NO 20A 12V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 21108 pcs
Reference Price (In US Dollars)	100 pcs
Reference Price (In US Dollars)	$1.567

Product parameter
Data sheet

Product parameter

Part Number	V2D1S00B-00000-000	Manufacturer	Carling Technologies
Description	SWITCH ROCKER SPST-NO 20A 12V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	21108 pcs	Data sheet	V & L Series Legend Codes V Series Datasheet
Category	Switches	Voltage Rating - DC	12V
Termination Style	Quick Connect - 0.250" (6.3mm)	Switch Function	Off-Mom
Series	V-Series Contura	Panel Cutout Dimensions	Rectangular - 36.83mm x 21.08mm
Packaging	Bulk	Other Names	432-1298 V2D1S00B00000000
Operating Temperature	-40°C ~ 85°C	Mounting Type	Panel Mount, Snap-In
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	150,000 Cycles
Manufacturer Standard Lead Time	6 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	IP66/68 - Dust Tight, Water Resistant, Waterproof	Illumination Voltage (Nominal)	-
Illumination Type, Color	-	Features	-
Electrical Life	50,000 Cycles	Detailed Description	Rocker Switch SPST-NO 20A (DC) Panel Mount, Snap-In
Current Rating	20A (DC)	Color - Actuator/Cap	-
Circuit	SPST-NO	Actuator Type	Actuator Arm, Cap Required
Actuator Marking	Varies by Cap
