CPPLX4-A7BRNP
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CPPLX4-A7BRNP with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CPPLX4-A7BRNP with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CPPLX4-A7BRNP |
|---|---|
| Manufacturer | Cardinal Components |
| Description | OSC BLANK HALF SIZE 100 OR 50PPM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 120 pcs | |
|---|---|---|---|---|---|
| $1.806 | $1.713 | $1.618 | $1.522 | ||
| 600 pcs | 1080 pcs | 2520 pcs | |||
| $1.475 | $1.265 | $1.189 | |||
- Product parameter
Product parameter
| Part Number | CPPLX4-A7BRNP | Manufacturer | Cardinal Components |
|---|---|---|---|
| Description | OSC BLANK HALF SIZE 100 OR 50PPM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 27227 pcs | Data sheet | |
| Category | Crystals, Oscillators, Resonators | Voltage - Supply | 5V |
| Type | XO (Standard) | Spread Spectrum Bandwidth | - |
| Size / Dimension | 0.520" L x 0.520" W (13.20mm x 13.20mm) | Series | FIPO™ CPPL |
| Ratings | - | Programmable Type | Blank (User Must Program) |
| Packaging | Tube | Package / Case | 8-DIP, 4 Leads (Half Size, Metal Can) |
| Output | CMOS, TTL | Other Names | CPPLX4-A7BR-XX.XXXNC CPPLX4-A7BRNP-ND CPPLX4A7BRNP LX4HS |
| Operating Temperature | -40°C ~ 85°C | Mounting Type | Through Hole |
| Manufacturer Standard Lead Time | 2 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height | 0.220" (5.60mm) | Function | Enable/Disable, Standby |
| Frequency Stability (Total) | - | Frequency Stability | ±25ppm |
| Detailed Description | XO (Standard) CMOS, TTL 1MHz ~ 133MHz Programmable Oscillator 5V Enable/Disable, Standby 8-DIP, 4 Leads (Half Size, Metal Can) | Current - Supply (Max) | 45mA |
| Current - Supply (Disable) (Max) | 20µA | Base Resonator | Crystal |
| Available Frequency Range | 1MHz ~ 133MHz |
