PLB4G820003
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PLB4G820003 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PLB4G820003 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PLB4G820003 |
|---|---|
| Manufacturer | Cannon |
| Description | CONN RCPT FMALE 3POS SOLDER CUP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $5.709 | $5.189 | $4.411 | |||
| 250 pcs | 500 pcs | 1000 pcs | |||
| $4.021 | $3.762 | $3.451 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | PLB4G820003 | Manufacturer | Cannon |
|---|---|---|---|
| Description | CONN RCPT FMALE 3POS SOLDER CUP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 9415 pcs | Data sheet | PL Series BrochurePLB(1,3,4) Series Drawing |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Solder Cup | Shielding | Unshielded |
| Shell Size, MIL | - | Shell Size - Insert | 9-35 |
| Shell Material | Polysulfone (PSU) | Shell Finish | - |
| Series | PL | Packaging | Bulk |
| Other Names | 1003-2797 132043-4384 |
Orientation | 0° |
| Operating Temperature | -50°C ~ 150°C | Number of Positions | 3 |
| Mounting Type | Panel Mount | Mounting Feature | Bulkhead - Front or Rear Side Nut |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material Flammability Rating | - |
| Manufacturer Standard Lead Time | 9 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insert Material | Polyetheretherketone (PEEK) | Ingress Protection | IP50 - Dust Protected |
| Features | - | Fastening Type | Latch Lock, Push-Pull |
| Detailed Description | 3 Position Circular Connector Receptacle, Female Sockets Solder Cup Gold | Current Rating | 10A |
| Contact Material | Copper Alloy | Contact Finish Thickness - Mating | 20.0µin (0.51µm) |
| Contact Finish - Mating | Gold | Connector Type | Receptacle, Female Sockets |
| Color | Gray | Cable Opening | - |
| Backshell Material, Plating | - | Applications | Industrial, Medical, Testing Equipment & Measurement |
