Home > Products > Connectors, Interconnects > D-Sub, D-Shaped Connectors - Accessories > DB22255

DB22255

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DB22255 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	DB22255
Manufacturer	Cannon
Description	DSUB GUIDE PIN PLATE MALE
Lead Free Status / RoHS Status	Vendor undefined / Vendor undefined

~~In Stock~~ 4598 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	100 pcs	250 pcs	500 pcs
Reference Price (In US Dollars)	$9.513	$8.587	$7.456	$7.045	$6.839

Product parameter

Product parameter

Part Number	DB22255	Manufacturer	Cannon
Description	DSUB GUIDE PIN PLATE MALE	Lead Free Status / RoHS Status	Vendor undefined / Vendor undefined
Quantity Available	4598 pcs	Data sheet
Category	Connectors, Interconnects	Series	-
Other Names	022255-0000 1003-1745 222550000 DB22255-ND IDB22255 IDB22255-ND	Number of Positions	25
Manufacturer Standard Lead Time	21 Weeks	Lead Free Status / RoHS Status	Vendor undefined / Vendor undefined
For Use With/Related Products	D-Sub Connectors, Male	Features	Hardware Included
Detailed Description	Connector Guide Plate, Locator For D-Sub Connectors, Male	Accessory Type	Guide Plate, Locator
