VAWQ3-Q24-D12H
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy VAWQ3-Q24-D12H with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy VAWQ3-Q24-D12H with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | VAWQ3-Q24-D12H |
|---|---|
| Manufacturer | CUI, Inc. |
| Description | DC DC CONVERTER +/-12V 3W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $7.722 | $7.661 | $7.601 | $7.483 | ||
| 50 pcs | 100 pcs | 250 pcs | 500 pcs | ||
| $7.126 | $6.532 | $6.414 | $6.319 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | VAWQ3-Q24-D12H | Manufacturer | CUI, Inc. |
|---|---|---|---|
| Description | DC DC CONVERTER +/-12V 3W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5583 pcs | Data sheet | VAWQ3 Series |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -12V | Voltage - Output 1 | 12V |
| Voltage - Isolation | 3kV | Voltage - Input (Min) | 9V |
| Voltage - Input (Max) | 36V | Type | Isolated Module |
| Size / Dimension | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) | Series | VAWQ3 |
| Power (Watts) | 3W | Packaging | Tube |
| Package / Case | 24-DIP Module, 15 Leads | Other Names | 102-1314 659-40604R VAWQ3Q24D12H |
| Operating Temperature | -25°C ~ 71°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | SCP |
| Efficiency | 72% | Detailed Description | Isolated Module DC DC Converter 2 Output 12V -12V 125mA, 125mA 9V - 36V Input |
| Current - Output (Max) | 125mA, 125mA | California Prop 65 | Warning Information WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov. |
| Applications | ITE (Commercial) |
