SR-2501
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SR-2501 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SR-2501 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SR-2501 |
|---|---|
| Manufacturer | CUI, Inc. |
| Description | CONN JACK STEREO 2.5MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.727 | $0.659 | $0.619 | $0.592 | $0.565 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.511 | $0.471 | $0.404 | $0.377 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | SR-2501 | Manufacturer | CUI, Inc. |
|---|---|---|---|
| Description | CONN JACK STEREO 2.5MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 82174 pcs | Data sheet | SR-2501 |
| Category | Connectors, Interconnects | Voltage - Rated | - |
| Thread Size | - | Termination | Solder |
| Signal Lines | Stereo (3 Conductor, TRS) | Shielding | Unshielded |
| Series | - | Panel Hole Size | - |
| Packaging | Bulk | Other Names | 045-0949R CP-2521 SR2501 |
| Operating Temperature | -20°C ~ 70°C | Number of Positions/Contacts | 3 Conductors, 3 Contacts |
| Mounting Type | Free Hanging (In-Line) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Length/Depth | - | Manufacturer Standard Lead Time | 14 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Internal Switch(s) | Does Not Contain Switch |
| Insulation Color | - | Industry Recognized Mating Diameter | 2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone |
| Includes | - | Housing Material | Polyamide (PA), Nylon |
| Gender | Female | Features | - |
| Detailed Description | 2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone Phone Jack Stereo (3 Conductor, TRS) Connector Solder | Contact Material - Plating | Nickel |
| Contact Material | Brass, Phosphor Bronze | Connector Type | Phone Jack |
| California Prop 65 | Warning Information WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov. | Cable Opening | 0.157" (4.00mm) |
| Body Material | - | Body Color | Black |
| Actual Diameter | 0.102" (2.60mm) |
