PYB15-Q24-D12-H
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PYB15-Q24-D12-H with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PYB15-Q24-D12-H with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PYB15-Q24-D12-H |
|---|---|
| Manufacturer | CUI, Inc. |
| Description | DC DC CONVERTER +/-12V 15W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 45 pcs | ||||
|---|---|---|---|---|---|
| $12.598 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | PYB15-Q24-D12-H | Manufacturer | CUI, Inc. |
|---|---|---|---|
| Description | DC DC CONVERTER +/-12V 15W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2430 pcs | Data sheet | PYB15 Series |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -12V | Voltage - Output 1 | 12V |
| Voltage - Isolation | 1.5kV | Voltage - Input (Min) | 9V |
| Voltage - Input (Max) | 36V | Type | Isolated Module |
| Size / Dimension | 2.00" L x 1.00" W x 0.64" H (50.8mm x 25.4mm x 16.3mm) | Series | PYB15 |
| Power (Watts) | 15W | Packaging | Bulk |
| Package / Case | 6-DIP Module | Other Names | PYB15Q24D12H |
| Operating Temperature | -40°C ~ 85°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | OCP, OVP, SCP, UVLO |
| Efficiency | 88% | Detailed Description | Isolated Module DC DC Converter 2 Output 12V -12V 625mA, 625mA 9V - 36V Input |
| Current - Output (Max) | 625mA, 625mA | Control Features | Enable, Active High |
| California Prop 65 | Warning Information WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov. | Applications | ITE (Commercial) |
