PDS1-S5-D15-M
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PDS1-S5-D15-M with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PDS1-S5-D15-M with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PDS1-S5-D15-M |
|---|---|
| Manufacturer | CUI, Inc. |
| Description | DC DC CONVERTER +/-15V 1W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 15 pcs | 30 pcs | |
|---|---|---|---|---|---|
| $1.941 | $1.912 | $1.884 | $1.829 | ||
| 60 pcs | 105 pcs | 255 pcs | 510 pcs | ||
| $1.773 | $1.718 | $1.662 | $1.552 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PDS1-S5-D15-M | Manufacturer | CUI, Inc. |
|---|---|---|---|
| Description | DC DC CONVERTER +/-15V 1W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 25373 pcs | Data sheet | PDS1-M Series |
| Category | Power Supplies - Board Mount | Voltage - Output 4 | - |
| Voltage - Output 3 | - | Voltage - Output 2 | -15V |
| Voltage - Output 1 | 15V | Voltage - Isolation | 1.5kV |
| Voltage - Input (Min) | 4.5V | Voltage - Input (Max) | 5.5V |
| Type | Isolated Module | Supplier Device Package | - |
| Size / Dimension | 0.60" L x 0.33" W x 0.29" H (15.2mm x 8.3mm x 7.3mm) | Series | PDS1-M |
| Power (Watts) | 1W | Package / Case | 10-SMD Module, 6 Leads, Gull Wing |
| Other Names | 102-4554 PDS1-S5-D15-M-ND |
Operating Temperature | -40°C ~ 105°C |
| Number of Outputs | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 8 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Efficiency | 81% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 15V -15V 33mA, 33mA 4.5V - 5.5V Input | Current - Output (Max) | 33mA, 33mA |
| Control Features | - | California Prop 65 | Warning Information WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov. |
| Applications | ITE (Commercial) |
