PB1-36CB
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PB1-36CB with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PB1-36CB with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PB1-36CB |
|---|---|
| Manufacturer | CTS Electronic Components |
| Description | HEATSINK VERT .50"H BLK TO-220 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.387 | $0.366 | $0.357 | $0.347 | $0.328 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.309 | $0.289 | $0.27 | $0.26 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PB1-36CB | Manufacturer | CTS Electronic Components |
|---|---|---|---|
| Description | HEATSINK VERT .50"H BLK TO-220 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 84440 pcs | Data sheet | PB1-36, PSB2-1 SeriesPSB2,PB1 |
| Category | Fans, Thermal Management | Width | 1.000" (25.40mm) |
| Type | Board Level, Vertical | Thermal Resistance @ Natural | 20.00°C/W |
| Thermal Resistance @ Forced Air Flow | - | Shape | Rectangular, Fins |
| Series | PB1-36 | Power Dissipation @ Temperature Rise | 1.0W @ 70°C |
| Package Cooled | TO-126, TO-127, TO-220 | Other Names | 294-1042 PB136CB |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 11 Weeks |
| Length | 1.180" (29.97mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.500" (12.70mm) | Diameter | - |
| Detailed Description | Heat Sink TO-126, TO-127, TO-220 Aluminum 1.0W @ 70°C Board Level, Vertical | Attachment Method | Bolt On and PC Pin |
