CR8420-1000-PCB
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CR8420-1000-PCB with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CR8420-1000-PCB with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CR8420-1000-PCB |
|---|---|
| Manufacturer | CR Magnetics, Inc. |
| Description | CURR SENSE XFMR IN-LINE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $5.337 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | CR8420-1000-PCB | Manufacturer | CR Magnetics, Inc. |
|---|---|---|---|
| Description | CURR SENSE XFMR IN-LINE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6240 pcs | Data sheet | CR8400 Series |
| Category | Transformers | Weight | - |
| Type | Non-Invasive (Solid Core) | Turns Ratio - Primary:Secondary | - |
| Termination Style | Wire Leads | Size / Dimension | 1.417" L x 1.181" W (36.00mm x 30.00mm) |
| Series | CR8400 | Ratings | - |
| Packaging | Bulk | Other Names | 582-1085 CR8420-1000-PCB-ND CR84201000PCB Q4079421 |
| Mounting Type | Free Hanging (In-Line) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 0.362" (9.20mm) | Frequency Range | 20Hz ~ 1kHz |
| Energy Time (E.T.) | - | Detailed Description | Current Sense Transformer 20Hz ~ 1kHz Free Hanging (In-Line) |
| DC Resistance (DCR) | - | Current Ratio | - |
