SD10H1SBD
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SD10H1SBD with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SD10H1SBD with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SD10H1SBD |
|---|---|
| Manufacturer | C&K |
| Description | SWITCH SLIDE DIP SPST 100MA 25V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 20 pcs | 40 pcs | 60 pcs | |
|---|---|---|---|---|---|
| $1.353 | $1.296 | $1.24 | $1.183 | ||
| 100 pcs | 260 pcs | 500 pcs | 1000 pcs | ||
| $1.042 | $0.986 | $0.958 | $0.817 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | SD10H1SBD | Manufacturer | C&K |
|---|---|---|---|
| Description | SWITCH SLIDE DIP SPST 100MA 25V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 40999 pcs | Data sheet | SD Series Dip Datasheet |
| Category | Switches | Washable | No |
| Voltage Rating | 25VDC | Termination Style | Gull Wing |
| Series | SD | Pitch | 0.100" (2.54mm), Full |
| Packaging | Tube | Other Names | CKN11914 SD10H1SBD-ND SER2LBKRDGNAU0A |
| Operating Temperature | -40°C ~ 85°C | Number of Positions | 10 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mechanical Life | 2,000 Cycles | Manufacturer Standard Lead Time | 13 Weeks |
| Length | 1.058" (26.87mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Above Board | 0.165" (4.20mm) | Features | - |
| Electrical Life | 2,000 Cycles | Detailed Description | Dip Switch SPST 10 Position Surface Mount Slide (Standard) Actuator 100mA 25VDC |
| Current Rating | 100mA | Contact Material | Beryllium Copper |
| Contact Finish | Gold | Circuit | SPST |
| Body Material | Polyphthalamide (PPA) | Actuator Type | Slide (Standard) |
| Actuator Level | Raised |
