SD04H1BD
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SD04H1BD with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SD04H1BD with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SD04H1BD |
|---|---|
| Manufacturer | C&K |
| Description | SWITCH SLIDE DIP SPST 100MA 25V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 45 pcs | 90 pcs | 135 pcs |
|---|---|---|---|---|---|
| $0.577 | $0.543 | $0.521 | $0.488 | $0.476 | |
| 270 pcs | 540 pcs | 1035 pcs | 5040 pcs | ||
| $0.421 | $0.399 | $0.355 | $0.31 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | SD04H1BD | Manufacturer | C&K |
|---|---|---|---|
| Description | SWITCH SLIDE DIP SPST 100MA 25V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 66380 pcs | Data sheet | SD Series Dip Datasheet |
| Category | Switches | Washable | No |
| Voltage Rating | 25VDC | Termination Style | PC Pin |
| Series | SD | Pitch | 0.100" (2.54mm), Full |
| Packaging | Tube | Other Names | *7101SDV3QE *SD04H1BD CKN10988 SD04H1BD-ND |
| Operating Temperature | -40°C ~ 85°C | Number of Positions | 4 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mechanical Life | 2,000 Cycles | Manufacturer Standard Lead Time | 13 Weeks |
| Length | 0.458" (11.63mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Above Board | 0.178" (4.52mm) | Features | - |
| Electrical Life | 2,000 Cycles | Detailed Description | Dip Switch SPST 4 Position Through Hole Slide (Standard) Actuator 100mA 25VDC |
| Current Rating | 100mA | Contact Material | Beryllium Copper |
| Contact Finish | Gold | Circuit | SPST |
| Body Material | Polyphthalamide (PPA) | Actuator Type | Slide (Standard) |
| Actuator Level | Raised |
