Home > Products > Switches > Keylock Switches > P2011U3WM03NQ2

P2011U3WM03NQ2

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy P2011U3WM03NQ2 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	P2011U3WM03NQ2
Manufacturer	C&K
Description	SWITCH KEYLOCK 2POS DPDT 4A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 5656 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	P2011U3WM03NQ2	Manufacturer	C&K
Description	SWITCH KEYLOCK 2POS DPDT 4A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	5656 pcs	Data sheet	P Series Snap-in Switchlocks
Category	Switches	Voltage Rating - DC	28V
Voltage Rating - AC	125V	Termination Style	Solder Lug
Switch Function	On-On	Series	P
Panel Cutout Dimensions	Circular - 19.30mm Dia	Other Names	*P2011U3WM03NQ2 CKC8035 P2011U3WM03NQ2-ND
Operating Temperature	-30°C ~ 65°C	Number of Positions	2
Mounting Type	Panel Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Key Removable Positions	All	Features	-
Electrical Life	10,000 Cycles	Detailed Description	Keylock Switch 2 Position DPDT 4A (AC/DC) 125VAC 28VDC Panel Mount
Depth Behind Flange	15.60mm	Current Rating	4A (AC/DC)
Contact Timing	Not Specified	Contact Material	Copper
Contact Finish	Silver	Circuit	DPDT
Angle of Throw	90°	Actuator Type	Flat Key
