Home > Products > Switches > Rotary Switches > MB05L2NCGD

MB05L2NCGD

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MB05L2NCGD with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MB05L2NCGD
Manufacturer	C&K
Description	SWITCH ROTARY 5POS 250MA 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs
~~In Stock~~ 6997 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$5.633	$5.257	$5.182	$5.107
	$4.506	$4.356	$4.28

Product parameter
Data sheet

Product parameter

Part Number	MB05L2NCGD	Manufacturer	C&K
Description	SWITCH ROTARY 5POS 250MA 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	6997 pcs	Data sheet	M Series Datasheet
Category	Switches	Voltage Rating - DC	28V
Voltage Rating - AC	125V	Termination Style	PC Pin
Series	M	Panel Cutout Dimensions	Circular - 6.60mm Dia
Other Names	*MB05L2NCGD CKN11248 MB05L2NCGD-ND	Operating Force	2.880 ~ 5.041gfm
Number of Positions	5	Number of Poles per Deck	2
Number of Decks	1	Mounting Type	Panel Mount, Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	13 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Index Stops	Fixed
Features	-	Detailed Description	Rotary Switch 5 Position DP5T 250mA (AC/DC) 125VAC Panel Mount, Through Hole
Depth Behind Panel	10.42mm	Current Rating	250mA (AC/DC)
Contact Timing	Non-Shorting (BBM)	Contact Material	Copper Alloy
Contact Finish	Gold	Circuit per Deck	DP5T
Angle of Throw	36°	Actuator Type	Screwdriver Slot
Actuator Length	Flush
