Home > Products > Switches > Rocker Switches > 7203J1ZQE2

7203J1ZQE2

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 7203J1ZQE2 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	7203J1ZQE2
Manufacturer	C&K
Description	SWITCH ROCKER DPDT 5A 120V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 9941 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$4.593	$4.133	$4.018	$3.903
	$3.788	$3.673	$3.214	$3.042

Product parameter
Data sheet

Product parameter

Part Number	7203J1ZQE2	Manufacturer	C&K
Description	SWITCH ROCKER DPDT 5A 120V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	9941 pcs	Data sheet	7000 Series Mini Rocker Datasheet Rockers Product Guide
Category	Switches	Voltage Rating - DC	28V
Voltage Rating - AC	120V	Termination Style	Solder Lug
Switch Function	On-Off-On	Series	7000
Panel Cutout Dimensions	Rectangular - 17.96mm x 10.62mm	Packaging	Bulk
Other Names	7203J1ZQE2-ND CKN11657	Operating Temperature	-30°C ~ 85°C
Mounting Type	Panel Mount, Flange	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	-	Manufacturer Standard Lead Time	11 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Illumination Voltage (Nominal)	-	Illumination Type, Color	-
Features	Epoxy Sealed Terminals	Electrical Life	40,000 Cycles
Detailed Description	Rocker Switch DPDT 5A (AC/DC) 120V Panel Mount, Flange	Current Rating	5A (AC/DC)
Color - Actuator/Cap	Black	Circuit	DPDT
Actuator Type	Concave (Standard V)	Actuator Marking	No Marking
