Home > Products > Switches > Toggle Switches > 7101P3YZQE22

7101P3YZQE22

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 7101P3YZQE22 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	7101P3YZQE22
Manufacturer	C&K
Description	SWITCH TOGGLE SPDT 5A 120V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 14201 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$3.616	$3.521	$3.426	$3.236
	$3.141	$3.045	$2.57	$2.474

Product parameter
Data sheet

Product parameter

Part Number	7101P3YZQE22	Manufacturer	C&K
Description	SWITCH TOGGLE SPDT 5A 120V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	14201 pcs	Data sheet	7000 Series Mini Toggle Datasheet
Category	Switches	Voltage Rating - DC	28V
Voltage Rating - AC	120V	Termination Style	Solder Lug
Switch Function	On-On	Series	7000
Panel Cutout Dimensions	Circular - 6.35mm Dia	Packaging	Bulk
Other Names	*7101P3YZQE22 CKN9676	Operating Temperature	-30°C ~ 85°C
Mounting Type	Panel Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	11 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Illumination Voltage (Nominal)	-
Illumination Type, Color	-	Illumination	Non-Illuminated
Features	Black Actuator	Electrical Life	100,000 Cycles
Detailed Description	Toggle Switch SPDT Panel Mount	Current Rating	5A (AC/DC)
Circuit	SPDT	Bushing Thread	1/4-40
Actuator Type	Flat Anti-Rotation	Actuator Material	Brass
Actuator Length	11.43mm
