Home > Products > Switches > Toggle Switches > 7101P3CWAV2ME

7101P3CWAV2ME

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 7101P3CWAV2ME with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	7101P3CWAV2ME
Manufacturer	C&K
Description	SWITCH TOGGLE SPDT 5A 120V
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 16197 pcs
Reference Price (In US Dollars)	500 pcs
Reference Price (In US Dollars)	$2.204

Product parameter
Data sheet

Product parameter

Part Number	7101P3CWAV2ME	Manufacturer	C&K
Description	SWITCH TOGGLE SPDT 5A 120V	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	16197 pcs	Data sheet	7000 Series Toggle Datasheet
Category	Switches	Voltage Rating - DC	28V
Voltage Rating - AC	120V	Termination Style	PC Pin
Switch Function	On-On	Series	7000
Panel Cutout Dimensions	Circular - 6.35mm Dia	Packaging	Bulk
Other Names	*7101P3CWAV2ME CKN9674	Operating Temperature	-30°C ~ 85°C
Mounting Type	Panel Mount, Right Angle, Vertical	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	11 Weeks	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Ingress Protection	IP67 - Dust Tight, Waterproof	Illumination Voltage (Nominal)	-
Illumination Type, Color	-	Illumination	Non-Illuminated
Features	Epoxy Sealed Terminals	Electrical Life	100,000 Cycles
Detailed Description	Toggle Switch SPDT Panel Mount, Right Angle, Vertical	Current Rating	5A (AC/DC)
Circuit	SPDT	Bushing Thread	1/4-40
Actuator Type	Flat Anti-Rotation	Actuator Material	Brass, Chrome Plated
Actuator Length	11.43mm
