TCF80
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TCF80 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TCF80 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TCF80 |
|---|---|
| Manufacturer | Bussmann (Eaton) |
| Description | FUSE RECT 80A 600VAC/300VDC BLAD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $56.654 | $53.671 | $50.69 | $42.937 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | TCF80 | Manufacturer | Bussmann (Eaton) |
|---|---|---|---|
| Description | FUSE RECT 80A 600VAC/300VDC BLAD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 848 pcs | Data sheet | CUBEFuse® TCF(RN) Series DatasheetTCF Low-Peak™ CUBEFuse™ Product Guide |
| Category | Circuit Protection | Voltage Rating - DC | 300V |
| Voltage Rating - AC | 600V | Size / Dimension | 1.880" L x 0.750" W x 1.270" H (47.75mm x 19.05mm x 32.26mm) |
| Series | CUBEFuse™ TCF | Response Time | Slow |
| Packaging | Bulk | Package / Case | Blade Type, Module |
| Other Names | 283-3506 TCF80-ND |
Operating Temperature | -40°C ~ 80°C |
| Mounting Type | Holder | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 6 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Fuse Type | Rectangular | Features | Indicating |
| Current Rating | 80A | Class | - |
| Breaking Capacity @ Rated Voltage | 300kA AC, 100kA DC | Approvals | CE, CSA, UL |
| Applications | Electrical, Industrial |
