SD7030-101-R
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SD7030-101-R with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SD7030-101-R with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SD7030-101-R |
|---|---|
| Manufacturer | Bussmann (Eaton) |
| Description | FIXED IND 95.5UH 700MA 535 MOHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1500 pcs | ||||
|---|---|---|---|---|---|
| $0.309 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SD7030-101-R | Manufacturer | Bussmann (Eaton) |
|---|---|---|---|
| Description | FIXED IND 95.5UH 700MA 535 MOHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 76047 pcs | Data sheet | SD7030 Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±30% | Supplier Device Package | - |
| Size / Dimension | 0.276" L x 0.276" W (7.00mm x 7.00mm) | Shielding | Shielded |
| Series | SD7030 | Ratings | - |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Other Names | 513-1489-2 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Manufacturer Standard Lead Time | 13 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 100kHz | Inductance | 95.5µH |
| Height - Seated (Max) | 0.118" (3.00mm) | Frequency - Self Resonant | - |
| Detailed Description | 95.5µH Shielded Wirewound Inductor 700mA 535 mOhm Max Nonstandard | DC Resistance (DCR) | 535 mOhm Max |
| Current Rating | 700mA | Current - Saturation | 540mA |
