Home > Products > Circuit Protection > Electrical, Specialty Fuses > PV-1A10F

PV-1A10F

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PV-1A10F with confidence from Components-World.HK, 1 Year Warranty

Dowload PV-1A10F Details in PDF

Request a Quote

Part Number	PV-1A10F
Manufacturer	Bussmann (Eaton)
Description	FUSE CARTRIDGE 1A 1KVDC 5AG
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	50 pcs	100 pcs	250 pcs
~~In Stock~~ 5466 pcs
Reference Price (In US Dollars)	1 pcs	5 pcs	10 pcs
	$10.325	$9.833	$9.096
	$7.867	$7.375	$7.08

Product parameter
Data sheet

Product parameter

Part Number	PV-1A10F	Manufacturer	Bussmann (Eaton)
Description	FUSE CARTRIDGE 1A 1KVDC 5AG	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	5466 pcs	Data sheet	10x38mm Photovoltaic Fuse Tech Data
Category	Circuit Protection	Voltage Rating - DC	1kV
Size / Dimension	0.406" Dia x 1.496" L (10.30mm x 38.00mm)	Series	PV
Response Time	-	Packaging	Bulk
Package / Case	5AG, 10mm x 38.1mm	Other Names	283-3507 PV1A10F
Operating Temperature	-40°C ~ 90°C	Mounting Type	Holder
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Melting I²t	0.15
Manufacturer Standard Lead Time	5 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Fuse Type	Cartridge	Features	-
Current Rating	1A	Class	-
Breaking Capacity @ Rated Voltage	50kA	Approvals	CCC, CSA, UL
Applications	Solar (Photovoltaic)
