HCM0503-5R6-R
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HCM0503-5R6-R with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HCM0503-5R6-R with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HCM0503-5R6-R |
|---|---|
| Manufacturer | Bussmann (Eaton) |
| Description | FIXED IND 5.6UH 4.3A 71 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 2000 pcs | ||||
|---|---|---|---|---|---|
| $0.164 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | HCM0503-5R6-R | Manufacturer | Bussmann (Eaton) |
|---|---|---|---|
| Description | FIXED IND 5.6UH 4.3A 71 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 131371 pcs | Data sheet | HCM0503 Series Datasheet |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.203" L x 0.201" W (5.15mm x 5.10mm) | Shielding | Shielded |
| Series | HCM0503 | Ratings | - |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Core | Iron Powder | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance Frequency - Test | 100kHz |
| Inductance | 5.6µH | Height - Seated (Max) | 0.118" (3.00mm) |
| Frequency - Self Resonant | - | Detailed Description | 5.6µH Shielded Wirewound Inductor 4.3A 71 mOhm Max Nonstandard |
| DC Resistance (DCR) | 71 mOhm Max | Current Rating | 4.3A |
| Current - Saturation | 3.5A |
