CTX02-12236
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CTX02-12236 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CTX02-12236 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CTX02-12236 |
|---|---|
| Manufacturer | Bussmann (Eaton) |
| Description | FIXED IND 500UH 2.6A 200 MOHM TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | CTX02-12236 | Manufacturer | Bussmann (Eaton) |
|---|---|---|---|
| Description | FIXED IND 500UH 2.6A 200 MOHM TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5560 pcs | Data sheet | CTX02-12236 |
| Category | Inductors, Coils, Chokes | Type | Toroidal |
| Tolerance | - | Supplier Device Package | - |
| Size / Dimension | 1.224" Dia (31.08mm) | Shielding | Unshielded |
| Series | PFC | Ratings | - |
| Q @ Freq | - | Packaging | Bulk |
| Package / Case | Radial | Other Names | 513-1652 |
| Operating Temperature | -20°C ~ 105°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Iron Powder |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance Frequency - Test | 100kHz |
| Inductance | 500µH | Height - Seated (Max) | 0.750" (19.05mm) |
| Frequency - Self Resonant | - | Detailed Description | 500µH Unshielded Toroidal Inductor 2.6A 200 mOhm Max Radial |
| DC Resistance (DCR) | 200 mOhm Max | Current Rating | 2.6A |
| Current - Saturation | - |
