SRF1260-470M
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SRF1260-470M with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SRF1260-470M with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SRF1260-470M |
|---|---|
| Manufacturer | Bourns, Inc. |
| Description | INDUCT ARRAY 2 COIL 47UH SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $0.50 | $0.463 | $0.335 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | SRF1260-470M | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | INDUCT ARRAY 2 COIL 47UH SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 62979 pcs | Data sheet | SRF1260 Series |
| Category | Inductors, Coils, Chokes | Tolerance | ±20% |
| Size / Dimension | 0.492" L x 0.492" W (12.50mm x 12.50mm) | Shielding | Shielded |
| Series | SRF1260 | Ratings | - |
| Packaging | Original-Reel® | Package / Case | Nonstandard |
| Other Names | SRF1260-470MDKR | Operating Temperature | -40°C ~ 125°C |
| Number of Coils | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 18 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance - Connected In Series | 188µH |
| Inductance - Connected In Parallel | 47µH | Height | 0.244" (6.20mm) |
| Detailed Description | Shielded 2 Coil Inductor Array 188µH Inductance - Connected in Series 47µH Inductance - Connected in Parallel 86 mOhm Max DC Resistance (DCR) - Parallel 2.71A Nonstandard | DC Resistance (DCR) - Series | 340 mOhm Max |
| DC Resistance (DCR) - Parallel | 86 mOhm Max | Current Saturation - Series | 1.62A |
| Current Saturation - Parallel | 3.24A | Current Rating - Series | 1.35A |
| Current Rating - Parallel | 2.71A |
