Home > Products > Circuit Protection > TVS - Diodes > SMBJ12A-QH

SMBJ12A-QH

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SMBJ12A-QH with confidence from Components-World.HK, 1 Year Warranty

Dowload SMBJ12A-QH Details in PDF

Request a Quote

Part Number	SMBJ12A-QH
Manufacturer	Bourns, Inc.
Description	TVS DIODE 12V 19.9V SMB
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 263931 pcs
Reference Price (In US Dollars)	2000 pcs
Reference Price (In US Dollars)	$0.075

Product parameter
Data sheet

Product parameter

Part Number	SMBJ12A-QH	Manufacturer	Bourns, Inc.
Description	TVS DIODE 12V 19.9V SMB	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	263931 pcs	Data sheet	SMBJ-Q Series Datasheet
Category	Circuit Protection	Voltage - Reverse Standoff (Typ)	12V
Voltage - Clamping (Max) @ Ipp	19.9V	Voltage - Breakdown (Min)	13.3V
Unidirectional Channels	1	Type	Zener
Supplier Device Package	SMB (DO-214AA)	Series	Automotive, AEC-Q101, SMBJ
Power Line Protection	No	Power - Peak Pulse	600W
Package / Case	DO-214AA, SMB	Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount	Manufacturer Standard Lead Time	16 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Current - Peak Pulse (10/1000µs)	30.2A
Capacitance @ Frequency	-	Applications	Automotive
