SDE6603-2R2M
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SDE6603-2R2M with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SDE6603-2R2M with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SDE6603-2R2M |
|---|---|
| Manufacturer | Bourns, Inc. |
| Description | FIXED IND 2.2UH 2.4A 70 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 6000 pcs | ||||
|---|---|---|---|---|---|
| $0.106 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SDE6603-2R2M | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | FIXED IND 2.2UH 2.4A 70 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 221088 pcs | Data sheet | SDE6603 Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.260" L x 0.175" W (6.60mm x 4.45mm) | Shielding | Unshielded |
| Series | SDE6603 | Ratings | - |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Operating Temperature | -25°C ~ 105°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Core | Ferrite | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance Frequency - Test | 100kHz |
| Inductance | 2.2µH | Height - Seated (Max) | 0.115" (2.92mm) |
| Frequency - Self Resonant | 90MHz | Detailed Description | 2.2µH Unshielded Wirewound Inductor 2.4A 70 mOhm Max Nonstandard |
| DC Resistance (DCR) | 70 mOhm Max | Current Rating | 2.4A |
| Current - Saturation | 2.3A |
