SDE1006A-5R6M
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SDE1006A-5R6M with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SDE1006A-5R6M with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SDE1006A-5R6M |
|---|---|
| Manufacturer | Bourns, Inc. |
| Description | FIXED IND 5.6UH 4.5A 40 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3200 pcs | ||||
|---|---|---|---|---|---|
| $0.123 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SDE1006A-5R6M | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | FIXED IND 5.6UH 4.5A 40 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 158003 pcs | Data sheet | SDE1006A Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.394" L x 0.354" W (10.00mm x 9.00mm) | Shielding | Unshielded |
| Series | SDE1006A | Ratings | AEC-Q200 |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Other Names | SDE1006A-5R6M-ND SDE1006A-5R6MTR |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Manufacturer Standard Lead Time | 20 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 1MHz | Inductance | 5.6µH |
| Height - Seated (Max) | 0.228" (5.80mm) | Frequency - Self Resonant | 35.6MHz |
| Detailed Description | 5.6µH Unshielded Wirewound Inductor 4.5A 40 mOhm Max Nonstandard | DC Resistance (DCR) | 40 mOhm Max |
| Current Rating | 4.5A | Current - Saturation | 5A |
