PT12136SL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PT12136SL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PT12136SL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PT12136SL |
|---|---|
| Manufacturer | Bourns, Inc. |
| Description | FIXED IND 15MH 40MA 60 OHM TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | PT12136SL | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | FIXED IND 15MH 40MA 60 OHM TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4115 pcs | Data sheet | PT121 Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±10% | Supplier Device Package | - |
| Size / Dimension | 0.400" Dia (10.15mm) | Shielding | Unshielded |
| Series | PT121 | Ratings | - |
| Q @ Freq | 100 @ 79.6kHz | Packaging | Bulk |
| Package / Case | Radial | Operating Temperature | -20°C ~ 80°C |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Core | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 79.6kHz | Inductance | 15mH |
| Height - Seated (Max) | 0.500" (12.70mm) | Frequency - Self Resonant | 400kHz |
| Detailed Description | 15mH Unshielded Wirewound Inductor 40mA 60 Ohm Max Radial | DC Resistance (DCR) | 60 Ohm Max |
| Current Rating | 40mA | Current - Saturation | - |
