PM75-100K-RC
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PM75-100K-RC with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PM75-100K-RC with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PM75-100K-RC |
|---|---|
| Manufacturer | Bourns, Inc. |
| Description | FIXED IND 10UH 2.3A 70 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $0.314 | $0.292 | $0.211 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | PM75-100K-RC | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | FIXED IND 10UH 2.3A 70 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 112137 pcs | Data sheet | PM75 Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±10% | Supplier Device Package | - |
| Size / Dimension | 0.307" L x 0.307" W (7.80mm x 7.80mm) | Shielding | Unshielded |
| Series | PM75 | Ratings | - |
| Q @ Freq | 25 @ 2.52MHz | Packaging | Original-Reel® |
| Package / Case | Nonstandard | Other Names | PM75-100K-RCDKR |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 1kHz | Inductance | 10µH |
| Height - Seated (Max) | 0.209" (5.30mm) | Frequency - Self Resonant | 22MHz |
| Detailed Description | 10µH Unshielded Wirewound Inductor 2.3A 70 mOhm Max Nonstandard | DC Resistance (DCR) | 70 mOhm Max |
| Current Rating | 2.3A | Current - Saturation | 3.2A |
