CHF3523DNT500LW
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CHF3523DNT500LW with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CHF3523DNT500LW with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CHF3523DNT500LW |
|---|---|
| Manufacturer | Bourns, Inc. |
| Description | RES SMD 50 OHM 5% 100W 3523 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | CHF3523DNT500LW | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | RES SMD 50 OHM 5% 100W 3523 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4649 pcs | Data sheet | CHF3523xNT Series |
| Category | Resistors | Tolerance | ±5% |
| Temperature Coefficient | - | Supplier Device Package | 3523 |
| Size / Dimension | 0.350" L x 0.230" W (8.89mm x 5.84mm) | Series | CHF - RF Power |
| Resistance | 50 Ohms | Power (Watts) | 100W |
| Packaging | Bulk | Package / Case | Nonstandard |
| Other Names | CHF3525DNT500LW CHF3525DNT500LW-ND |
Operating Temperature | -55°C ~ 150°C |
| Number of Terminations | 2 | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 0.039" (1.00mm) |
| Features | RF, High Frequency | Failure Rate | - |
| Detailed Description | 50 Ohms ±5% 100W Chip Resistor Nonstandard RF, High Frequency Thick Film | Composition | Thick Film |
