8230-70
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 8230-70 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 8230-70 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 8230-70 |
|---|---|
| Manufacturer | Bourns, Inc. |
| Description | FIXED IND 120UH 97MA 13 OHM TH |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 8230-70 | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | FIXED IND 120UH 97MA 13 OHM TH | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 4112 pcs | Data sheet | 8200 Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±10% | Supplier Device Package | Axial |
| Size / Dimension | 0.120" Dia x 0.300" L (3.05mm x 7.62mm) | Shielding | Unshielded |
| Series | 8230 | Ratings | - |
| Q @ Freq | 30 @ 790kHz | Packaging | Bulk |
| Package / Case | Axial | Other Names | M8038 |
| Operating Temperature | -55°C ~ 105°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Inductance Frequency - Test | 790kHz |
| Inductance | 120µH | Height - Seated (Max) | - |
| Frequency - Self Resonant | 12MHz | Detailed Description | 120µH Unshielded Wirewound Inductor 97mA 13 Ohm Max Axial |
| DC Resistance (DCR) | 13 Ohm Max | Current Rating | 97mA |
| Current - Saturation | - |
