SBC1505A
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SBC1505A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SBC1505A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SBC1505A |
|---|---|
| Manufacturer | Bomar (Winchester Electronics) |
| Description | CONN BNC PLUG STR 75 OHM CRIMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $2.052 | $1.968 | $1.64 | |||
| 250 pcs | 500 pcs | 1000 pcs | |||
| $1.435 | $1.394 | $1.189 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | SBC1505A | Manufacturer | Bomar (Winchester Electronics) |
|---|---|---|---|
| Description | CONN BNC PLUG STR 75 OHM CRIMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 29961 pcs | Data sheet | BNC Connectors |
| Category | Connectors, Interconnects | Voltage Rating | 500V |
| Shield Termination | Crimp | Series | - |
| Packaging | Bulk | Other Names | 991-1004 |
| Operating Temperature | - | Number of Ports | 1 |
| Mounting Type | Free Hanging (In-Line) | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Manufacturer Standard Lead Time | 15 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | 0.2dB | Ingress Protection | Weatherproof |
| Includes | - | Impedance | 75 Ohm |
| Housing Color | Silver | Frequency - Max | 1GHz |
| Features | - | Fastening Type | Bayonet Lock |
| Dielectric Material | - | Detailed Description | BNC Connector Plug, Male Pin 75 Ohm Free Hanging (In-Line) Crimp |
| Contact Termination | Crimp | Connector Type | Plug, Male Pin |
| Connector Style | BNC | Center Contact Plating | - |
| Center Contact Material | - | Cable Group | RG-59, Belden 1505A |
| Body Material | Brass | Body Finish | Nickel |
