561V504EFT
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 561V504EFT with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 561V504EFT with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 561V504EFT |
|---|---|
| Manufacturer | Bomar (Winchester Electronics) |
| Description | CONN TNC JACK STR 50OHM EDGE MNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 561V504EFT | Manufacturer | Bomar (Winchester Electronics) |
|---|---|---|---|
| Description | CONN TNC JACK STR 50OHM EDGE MNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4578 pcs | Data sheet | V-Bite PC Edge Mount |
| Category | Connectors, Interconnects | Voltage Rating | 500V |
| Shield Termination | Solder | Series | V-Bite® |
| Packaging | Bulk | Operating Temperature | -55°C ~ 200°C |
| Number of Ports | 1 | Mounting Type | Board Edge, End Launch; Panel Mount |
| Mounting Feature | Bulkhead - Front Side Nut | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Cycles | 500 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | 0.2dB | Ingress Protection | Weatherproof |
| Includes | - | Impedance | 50 Ohm |
| Housing Color | Silver | Frequency - Max | 18GHz |
| Features | Flange | Fastening Type | Threaded |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Detailed Description | TNC Connector Jack, Female Socket 50 Ohm Board Edge, End Launch; Panel Mount Solder |
| Contact Termination | Solder | Connector Type | Jack, Female Socket |
| Connector Style | TNC | Center Contact Plating | Gold |
| Center Contact Material | Phosphor Bronze | Cable Group | - |
| Body Material | Brass | Body Finish | Nickel |
