161V504E
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 161V504E with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 161V504E with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 161V504E |
|---|---|
| Manufacturer | Bomar (Winchester Electronics) |
| Description | CONN N JACK STR 50 OHM EDGE MNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | ||||
|---|---|---|---|---|---|
| $2.729 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 161V504E | Manufacturer | Bomar (Winchester Electronics) |
|---|---|---|---|
| Description | CONN N JACK STR 50 OHM EDGE MNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 11236 pcs | Data sheet | V-Bite PC Edge Mount |
| Category | Connectors, Interconnects | Voltage Rating | 1500V |
| Shield Termination | Solder | Series | V-Bite® |
| Packaging | Tray | Other Names | 991-1031 |
| Operating Temperature | -65°C ~ 165°C | Number of Ports | 1 |
| Mounting Type | Board Edge, End Launch | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Manufacturer Standard Lead Time | 15 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | 0.2dB | Ingress Protection | Weatherproof |
| Includes | - | Impedance | 50 Ohm |
| Housing Color | Silver | Frequency - Max | 11GHz |
| Features | - | Fastening Type | Threaded |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Detailed Description | N Type Connector Jack, Female Socket 50 Ohm Board Edge, End Launch Solder |
| Contact Termination | Solder | Connector Type | Jack, Female Socket |
| Connector Style | N Type | Center Contact Plating | Gold |
| Center Contact Material | Brass | Cable Group | - |
| Body Material | Brass | Body Finish | Nickel |
