Home > Products > Optoelectronics > LED Thermal Products > 803114

803114

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 803114 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	803114
Manufacturer	Bergquist
Description	SQU THERM CLAD BRD LUMEX SML-LX
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	500 pcs	1000 pcs	5000 pcs
~~In Stock~~ 103281 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	50 pcs	100 pcs
	$0.567	$0.505	$0.453	$0.401
	$0.348	$0.261	$0.226

Product parameter
Data sheet

Product parameter

Part Number	803114	Manufacturer	Bergquist
Description	SQU THERM CLAD BRD LUMEX SML-LX	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	103281 pcs	Data sheet	LED Solutions Guide Thermal Clad Selection Guide IMS LEDs Guide
Category	Optoelectronics	Type	Thermal Clad Board
Shape	Square	Series	Thermal Clad® IMS®
Packaging	1 per Pkg	Other Names	BER260
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	6 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	For Use With/Related Products	Lumex SML-LX
Detailed Description	Thermal Clad® IMS® Square Lumex SML-LX Thermal Clad Board
