36-8
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 36-8 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 36-8 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 36-8 |
|---|---|
| Manufacturer | Bel |
| Description | XFRMR LAMINATED 288VA CHAS MOUNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $39.103 | $37.799 | $35.192 | $34.671 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 36-8 | Manufacturer | Bel |
|---|---|---|---|
| Description | XFRMR LAMINATED 288VA CHAS MOUNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 899 pcs | Data sheet | Rectifier Power Transformers |
| Category | Transformers | Weight | 11 lbs (5kg) |
| Voltage - Secondary (Full Load) | Parallel 18V, Series 36V | Voltage - Primary | 105V, 115V, 125V, 230V |
| Voltage - Isolation | 1500Vrms | Type | Laminated Core |
| Termination Style | Solder, Quick Connect | Size / Dimension | 114.30mm L x 114.30mm W |
| Series | - | Secondary Winding(s) | Dual |
| Primary Winding(s) | Single, Multiple Taps | Power - Max | 288 VA |
| Other Names | 36-8-ND 595-1854 |
Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 95.30mm |
| Current - Output (Max) | Parallel 16A, Series 8A | Center Tap | Yes |
