26-8016
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 26-8016 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 26-8016 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 26-8016 |
|---|---|
| Manufacturer | Bel |
| Description | CONN ADAPT N PLUG TO BNC JACK |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $2.127 | $2.038 | $1.861 | $1.772 | $1.683 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $1.506 | $1.418 | $1.24 | $1.178 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 26-8016 | Manufacturer | Bel |
|---|---|---|---|
| Description | CONN ADAPT N PLUG TO BNC JACK | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 30654 pcs | Data sheet | 26-8016 Drawing |
| Category | Connectors, Interconnects | Style | Straight |
| Series | - | Packaging | Bulk |
| Other Names | 012446006010 26-8016-ND 268016 CP-AD809 CP-AD809-ND CPAD809 J10100 |
Operating Temperature | - |
| Mounting Type | Free Hanging (In-Line) | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | - |
| Manufacturer Standard Lead Time | 1 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Ingress Protection | - |
| Includes | - | Impedance | 50 Ohm |
| Frequency - Max | 4GHz | Features | - |
| Fastening Type | Bayonet Lock, Threaded | Dielectric Material | Polyoxymethylene (POM) Acetal |
| Detailed Description | Adapter Coaxial Connector N Plug, Male Pin To BNC Jack, Female Socket 50 Ohm | Convert To (Adapter End) | BNC Jack, Female Socket |
| Convert From (Adapter End) | N Plug, Male Pin | Conversion Type | Between Series |
| Center Gender | Female to Male | Center Contact Plating | Gold |
| Center Contact Material | Brass | Body Material | Brass |
| Body Finish | Nickel | Adapter Type | Plug to Jack |
| Adapter Series | BNC to N |
