133-8701-801
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 133-8701-801 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 133-8701-801 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 133-8701-801 |
|---|---|
| Manufacturer | Bel |
| Description | CONN MCX JACK STR 75OHM EDGE MNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.564 | $1.503 | $1.378 | $1.315 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.253 | $1.096 | $1.065 | $0.94 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 133-8701-801 | Manufacturer | Bel |
|---|---|---|---|
| Description | CONN MCX JACK STR 75OHM EDGE MNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 33408 pcs | Data sheet | 133-8701-801 Spec133-8701-801 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 335V |
| Shield Termination | Solder | Series | - |
| Packaging | Bulk | Other Names | 1338701801 J653 |
| Operating Temperature | -65°C ~ 165°C | Number of Ports | 1 |
| Mounting Type | Board Edge, End Launch | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Manufacturer Standard Lead Time | 7 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Ingress Protection | - |
| Includes | - | Impedance | 75 Ohm |
| Housing Color | Gold | Frequency - Max | 6GHz |
| Features | - | Fastening Type | Snap-On |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Detailed Description | MCX Connector Jack, Female Socket 75 Ohm Board Edge, End Launch Solder |
| Contact Termination | Solder | Connector Type | Jack, Female Socket |
| Connector Style | MCX | Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper | Cable Group | - |
| Body Material | Brass | Body Finish | Gold |
