HEDS-5540#H14
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HEDS-5540#H14 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HEDS-5540#H14 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HEDS-5540#H14 |
|---|---|
| Manufacturer | Avago Technologies (Broadcom Limited) |
| Description | ROTARY ENCODER OPTICAL 400PPR |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $23.974 | $21.152 | $15.512 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | HEDS-5540#H14 | Manufacturer | Avago Technologies (Broadcom Limited) |
|---|---|---|---|
| Description | ROTARY ENCODER OPTICAL 400PPR | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2281 pcs | Data sheet | HEDM_HEDS-55xx/560x/56xx |
| Category | Sensors, Transducers | Voltage - Supply | 5V |
| Termination Style | Terminal Pins | Series | HEDS |
| Rotational Life (Cycles Min) | - | Pulses per Revolution | 400 |
| Output Type | Quadrature with Index (Incremental) | Other Names | 516-2763 HEDS-5540#H14-ND HEDS5540H14 |
| Orientation | Vertical | Mounting Type | Chassis Mount, Motors |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 8 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Encoder Type | Optical |
| Detent | No | Built in Switch | No |
| Actuator Type | 5mm Open Center |
