HDSP-H3L1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HDSP-H3L1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HDSP-H3L1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HDSP-H3L1 |
|---|---|
| Manufacturer | Avago Technologies (Broadcom Limited) |
| Description | DISPLAY 7SEGMENT ORANGE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 8000 pcs | ||||
|---|---|---|---|---|---|
| $0.17 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | HDSP-H3L1 | Manufacturer | Avago Technologies (Broadcom Limited) |
|---|---|---|---|
| Description | DISPLAY 7SEGMENT ORANGE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 111097 pcs | Data sheet | HDSP-H3x1, HDSP-H3x3 |
| Category | Optoelectronics | Wavelength - Peak | 610nm |
| Voltage - Forward (Vf) (Typ) | 2V | Size / Dimension | 0.551" H x 0.295" W x 0.335" D (14.00mm x 7.50mm x 8.50mm) |
| Series | - | Power Dissipation (Max) | 52mW |
| Packaging | Tube | Package / Case | 10-DIP (0.200", 5.08mm) |
| Number of Characters | 1 | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Millicandela Rating | 13mcd | Manufacturer Standard Lead Time | 9 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Display Type | 7-Segment |
| Digit/Alpha Size | 0.36" (9.14mm) | Detailed Description | Character LED Display Module Orange 7-Segment 1 Character Common Anode 2V 20mA 0.551" H x 0.295" W x 0.335" D (14.00mm x 7.50mm x 8.50mm) 10-DIP (0.200", 5.08mm) |
| Current - Test | 20mA | Common Pin | Common Anode |
| Color | Orange |
