AP1155ADU
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AP1155ADU with confidence from Components-World.HK, 1 Year Warranty
Dowload AP1155ADU Details in PDFSee Product Specifications for product details.
Buy AP1155ADU with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AP1155ADU |
|---|---|
| Manufacturer | Asahi Kasei Microdevices / AKM Semiconductor |
| Description | IC REG LINEAR POS ADJ 1A TO252-5 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $0.676 | $0.611 | $0.546 | $0.491 | ||
| 250 pcs | 500 pcs | 1000 pcs | |||
| $0.437 | $0.382 | $0.317 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | AP1155ADU | Manufacturer | Asahi Kasei Microdevices / AKM Semiconductor |
|---|---|---|---|
| Description | IC REG LINEAR POS ADJ 1A TO252-5 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 61076 pcs | Data sheet | AP1155ADU |
| Category | Integrated Circuits (ICs) | Voltage Dropout (Max) | 0.49V @ 1A |
| Voltage - Output (Min/Fixed) | 1.3V | Voltage - Output (Max) | 14V |
| Voltage - Input (Max) | 15V | Supplier Device Package | TO-252-5 |
| Series | - | Protection Features | Over Current, Over Temperature, Reverse Polarity, Short Circuit |
| Packaging | Cut Tape (CT) | Package / Case | TO-252-6, DPak (5 Leads + Tab) |
| PSRR | 80dB (1kHz) | Output Type | Adjustable |
| Output Configuration | Positive | Other Names | AP1155ADUCT |
| Operating Temperature | -40°C ~ 85°C (TA) | Number of Regulators | 1 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Detailed Description | Linear Voltage Regulator IC Positive Adjustable 1 Output 1.3 V ~ 14 V 1A TO-252-5 |
| Current - Quiescent (Iq) | 100nA | Current - Output | 1A |
| Control Features | Enable |
