AWS24S
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AWS24S with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy AWS24S with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AWS24S |
|---|---|
| Manufacturer | Artaflex Inc. |
| Description | RF TXRX MODULE ISM>1GHZ U.FL ANT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | AWS24S | Manufacturer | Artaflex Inc. |
|---|---|---|---|
| Description | RF TXRX MODULE ISM>1GHZ U.FL ANT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4650 pcs | Data sheet | Hardware Design GuideAWS24S |
| Category | RF/IF and RFID | Voltage - Supply | 2.4 V ~ 3.6 V |
| Utilized IC / Part | CYRF7936 | Series | - |
| Serial Interfaces | SPI | Sensitivity | -97dBm |
| RF Family/Standard | General ISM > 1GHZ | Protocol | - |
| Power - Output | 4dBm | Packaging | Bulk |
| Package / Case | PCB Module | Other Names | 748-1001 |
| Operating Temperature | 0°C ~ 70°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Modulation | DSSS, GFSK |
| Memory Size | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Frequency | 2.4GHz | Data Rate | 1Mbps |
| Current - Transmitting | 18.4mA ~ 21.2mA | Current - Receiving | 20.8mA ~ 34.1mA |
| Antenna Type | Not Included, U.FL |
