AW24TH-SR
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AW24TH-SR with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy AW24TH-SR with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AW24TH-SR |
|---|---|
| Manufacturer | Artaflex Inc. |
| Description | RF TXRX MODULE 802.15.4 SMA ANT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $16.514 | $15.399 | $14.283 | $13.39 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | AW24TH-SR | Manufacturer | Artaflex Inc. |
|---|---|---|---|
| Description | RF TXRX MODULE 802.15.4 SMA ANT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2684 pcs | Data sheet | AW24TH-x |
| Category | RF/IF and RFID | Voltage - Supply | 2.7 V ~ 3.6 V |
| Utilized IC / Part | - | Series | - |
| Serial Interfaces | SPI, UART | Sensitivity | -105dBm |
| RF Family/Standard | 802.15.4 | Protocol | Zigbee® |
| Power - Output | 24.2dBm | Packaging | Tray |
| Package / Case | Module | Other Names | 748-1013 AW24TH-S-SM AW24THSSM |
| Operating Temperature | -40°C ~ 85°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Modulation | - |
| Memory Size | 256kB Flash, 8kB RAM | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Frequency | 2.4GHz |
| Data Rate | 250kbps | Current - Transmitting | 29mA |
| Current - Receiving | 24mA | Antenna Type | Not Included, SMA |
