C8120-04
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy C8120-04 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy C8120-04 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | C8120-04 |
|---|---|
| Manufacturer | Aries Electronics, Inc. |
| Description | CONN IC DIP SOCKET 20POS TIN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 32 pcs | ||||
|---|---|---|---|---|---|
| $1.265 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | C8120-04 | Manufacturer | Aries Electronics, Inc. |
|---|---|---|---|
| Description | CONN IC DIP SOCKET 20POS TIN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 31208 pcs | Data sheet | C81, C91 Series |
| Category | Connectors, Interconnects | Type | DIP, 0.3" (7.62mm) Row Spacing |
| Termination Post Length | 0.675" (17.15mm) | Termination | Wire Wrap |
| Series | Edge-Grip™, C81 | Pitch - Post | 0.100" (2.54mm) |
| Pitch - Mating | 0.100" (2.54mm) | Packaging | Bulk |
| Other Names | C81-20-04 C8120 |
Operating Temperature | -55°C ~ 105°C |
| Number of Positions or Pins (Grid) | 20 (2 x 10) | Mounting Type | Through Hole |
| Material Flammability Rating | UL94 V-0 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Material | Polyamide (PA46), Nylon 4/6, Glass Filled | Features | Closed Frame |
| Current Rating | 1.5A | Contact Resistance | - |
| Contact Material - Post | Phosphor Bronze | Contact Material - Mating | Phosphor Bronze |
| Contact Finish Thickness - Post | 200.0µin (5.08µm) | Contact Finish Thickness - Mating | 200.0µin (5.08µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Tin |
