Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - Expansion Boards, Daughter Car > TSX00083

TSX00083

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TSX00083 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	TSX00083
Manufacturer	Arduino.ORG
Description	PROTO SHIELD REV3
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 7521 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$4.343

Product parameter
Data sheet

Product parameter

Part Number	TSX00083	Manufacturer	Arduino.ORG
Description	PROTO SHIELD REV3	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	7521 pcs	Data sheet	TSX00083
Category	Development Boards, Kits, Programmers	Utilized IC / Part	-
Type	Protoboard	Series	-
Platform	Arduino	Other Names	1050-1167
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	8 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Function	Plated Through Hole
Detailed Description	Plated Through Hole Protoboard Arduino Platform Evaluation Expansion Board	Contents	Board(s)
