SA160DP
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SA160DP with confidence from Components-World.HK, 1 Year Warranty
Dowload SA160DP Details in PDFSee Product Specifications for product details.
Buy SA160DP with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SA160DP |
|---|---|
| Manufacturer | Apex Microtechnology |
| Description | IC BRIDGE DRVR ANLG/PWM 12SIP DP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | |||
|---|---|---|---|---|---|
| $72.456 | $68.958 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SA160DP | Manufacturer | Apex Microtechnology |
|---|---|---|---|
| Description | IC BRIDGE DRVR ANLG/PWM 12SIP DP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 537 pcs | Data sheet | 12-Power SIP DrawingSA160(A) Datasheet |
| Category | Integrated Circuits (ICs) | Voltage - Supply | 9.5 V ~ 15 V |
| Voltage - Load | 80V (Max) | Technology | Power MOSFET |
| Supplier Device Package | 12-POWER SIP | Series | - |
| Rds On (Typ) | 140 mOhm LS + HS | Packaging | Bulk |
| Package / Case | 12-PowerSIP | Output Configuration | Half Bridge (2) |
| Other Names | 1240-1006-5 | Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 10 Weeks | Load Type | Inductive |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Interface | Analog, PWM |
| Features | Internal Oscillators | Fault Protection | - |
| Detailed Description | Half Bridge (2) Driver DC Motors, General Purpose Power MOSFET 12-POWER SIP | Current - Peak Output | 15A |
| Current - Output / Channel | 10A | Applications | DC Motors, General Purpose |
