Home > Products > Integrated Circuits (ICs) > PMIC - Full, Half-Bridge Drivers > SA12L

SA12L

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SA12L with confidence from Components-World.HK, 1 Year Warranty

Dowload SA12L Details in PDF

Request a Quote

Part Number	SA12L
Manufacturer	Apex Microtechnology
Description	SWITCH AMP 200V 15A FULL BRIDGE
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 139 pcs
Reference Price (In US Dollars)	100 pcs
Reference Price (In US Dollars)	$221.905

Product parameter
Data sheet

Product parameter

Part Number	SA12L	Manufacturer	Apex Microtechnology
Description	SWITCH AMP 200V 15A FULL BRIDGE	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	139 pcs	Data sheet	SA12L
Category	Integrated Circuits (ICs)	Voltage - Supply	14 V ~ 16 V
Voltage - Load	16 V ~ 200 V	Technology	Power MOSFET
Supplier Device Package	12-PowerDip	Series	-
Rds On (Typ)	400 mOhm (Max)	Packaging	Bulk
Package / Case	12-PowerDIP, Module	Output Configuration	Half Bridge (2)
Operating Temperature	-55°C ~ 150°C (TJ)	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	11 Weeks
Load Type	Inductive, Capacitive	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Interface	PWM	Features	-
Fault Protection	Current Limiting, Over Temperature	Detailed Description	Half Bridge (2) Driver AC Motors, Piezo Devices Power MOSFET 12-PowerDip
Current - Peak Output	20A	Current - Output / Channel	15A
Applications	AC Motors, Piezo Devices
