SA03
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SA03 with confidence from Components-World.HK, 1 Year Warranty
Dowload SA03 Details in PDFSee Product Specifications for product details.
Buy SA03 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SA03 |
|---|---|
| Manufacturer | Apex Microtechnology |
| Description | IC MOTOR DRIVER PAR 12DIP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | |||
|---|---|---|---|---|---|
| $242.523 | $238.792 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SA03 | Manufacturer | Apex Microtechnology |
|---|---|---|---|
| Description | IC MOTOR DRIVER PAR 12DIP | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 148 pcs | Data sheet | SA03 |
| Category | Integrated Circuits (ICs) | Voltage - Supply | 14 V ~ 16 V |
| Voltage - Load | 16 V ~ 100 V | Technology | Power MOSFET |
| Supplier Device Package | 12-PowerDip | Series | Apex Precision Power® |
| Rds On (Typ) | 160 mOhm (Max) | Packaging | Tube |
| Package / Case | 12-PowerDIP, Module | Output Configuration | Half Bridge (2) |
| Other Names | 598-1452 598-1989 598-1989-ND SA03-ND |
Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 11 Weeks | Load Type | Inductive |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Interface | PWM |
| Features | - | Fault Protection | Current Limiting |
| Detailed Description | Half Bridge (2) Driver DC Motors, Piezo Devices Power MOSFET 12-PowerDip | Current - Peak Output | 40A |
| Current - Output / Channel | 30A | Base Part Number | SA* |
| Applications | DC Motors, Piezo Devices |
