SA01
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SA01 with confidence from Components-World.HK, 1 Year Warranty
Dowload SA01 Details in PDFSee Product Specifications for product details.
Buy SA01 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SA01 |
|---|---|
| Manufacturer | Apex Microtechnology |
| Description | IC MOTOR DRIVER PAR 10POWERDIP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $180.383 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SA01 | Manufacturer | Apex Microtechnology |
|---|---|---|---|
| Description | IC MOTOR DRIVER PAR 10POWERDIP | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 186 pcs | Data sheet | SA01(-6) |
| Category | Integrated Circuits (ICs) | Voltage - Supply | 16 V ~ 100 V |
| Voltage - Load | 16 V ~ 100 V | Technology | Power MOSFET |
| Supplier Device Package | 10-PowerDip | Series | Apex Precision Power® |
| Rds On (Typ) | 250 mOhm LS + HS | Packaging | Tube |
| Package / Case | 10-PowerDIP, Module | Output Configuration | Half Bridge (2) |
| Other Names | 598-1362 598-1994 598-1994-ND |
Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 11 Weeks | Load Type | Inductive |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Interface | Logic |
| Features | - | Fault Protection | Current Limiting, Over Temperature |
| Detailed Description | Half Bridge (2) Driver DC Motors, General Purpose Power MOSFET 10-PowerDip | Current - Peak Output | 30A |
| Current - Output / Channel | 20A | Base Part Number | SA* |
| Applications | DC Motors, General Purpose |
