Home > Products > Integrated Circuits (ICs) > Linear - Amplifiers - Instrumentation, OP Amps, Bu > PA85A

PA85A

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PA85A with confidence from Components-World.HK, 1 Year Warranty

Dowload PA85A Details in PDF

Request a Quote

Part Number	PA85A
Manufacturer	Apex Microtechnology
Description	IC OPAMP POWER 100MHZ TO3-8
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 487 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs
Reference Price (In US Dollars)	$82.636	$78.647	$75.797

Product parameter
Data sheet

Product parameter

Part Number	PA85A	Manufacturer	Apex Microtechnology
Description	IC OPAMP POWER 100MHZ TO3-8	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	487 pcs	Data sheet	TO-3-8 Pkg Drawing PA85(A) Drawing PA85 Accessories
Category	Integrated Circuits (ICs)	Voltage - Supply, Single/Dual (±)	30 V ~ 450 V, ±15 V ~ 225 V
Voltage - Input Offset	250µV	Supplier Device Package	TO-3-8
Slew Rate	1000 V/µs	Series	Apex Precision Power®
Packaging	Tube	Package / Case	TO-3-8
Output Type	-	Other Names	598-1327 598-2168-5 598-2168-5-ND
Operating Temperature	-25°C ~ 85°C	Number of Circuits	1
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	10 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Gain Bandwidth Product	100MHz	Detailed Description	Power Amplifier 1 Circuit TO-3-8
Current - Supply	21mA	Current - Output / Channel	200mA
Current - Input Bias	3pA	Base Part Number	PA85
Amplifier Type	Power
